GAC Aion S new energy vehicle range of 460 kilometers

Short Description:

GAC Aion S has a body length of 4768 mm x 1880 mm x 1530 mm, with a wheelbase of 2,750 mm. GAC Aion S has a maximum power of 100 kW, peak torque of 225N m, matching capacity of 58.8 KWH battery pack, comprehensive range of 460 km, 100 km acceleration of 7.9 seconds.

Product Detail

Product Tags

Product Information

AION S has a body length of 4768 mm x 1880 mm x 1530 mm, with a wheelbase of 2,750 mm. Its overall appearance is a bit like water droplets, the front face of cloud arrow is very handsome, suspension roof is also unconventional, particularly fashionable, especially the white body is particularly elegant. Moreover, Ian S vehicle quality sense is also very good, there is a so-called advanced sense, the steering wheel and the touch of the keys are very good. 12.3-inch instrument panel 12.3-inch central control large screen is very scientific and technological sense, work materials are very solid, almost all the touch is soft material, very high-end atmosphere show grade.

Panoramic skylight is not only a panoramic skylight with a wide view and can be opened, but also a hidden 'hidden technique'. It adopts the world's first solar energy self-circulation system, which can absorb solar energy in summer when the sun is too hot to automatically power the interior ventilation system, drive the air conditioning, keep the interior temperature at a comfortable temperature of about 10°C, so that you never have to worry about the car will become a 'big oven' in the hot summer. Can be said to be a practical and B - lattice black technology.

AION S has a maximum power of 100 kW, peak torque of 225N m, matching capacity of 58.8 KWH battery pack, comprehensive range of 460 km, 100 km acceleration of 7.9 seconds.

Product Specifications

Brand AION
Version 2022 XUAN 530
Car model Compact Car
Type of Energy Pure electric
NEDC pure electric cruising range (KM) 410
Maximum power (KW) 100
Maximum torque [Nm] 225
Motor horsepower [Ps] 136
Length*width*height (mm) 4768*1880*1530
Body structure 4-door 5-seat Sedan
Car body
Longth(mm) 4786
Width(mm) 1880
Higth(mm) 1530
Wheel base(mm) 2750
Minimum ground clearance (mm) 125
Body structure Sedan
Number of doors 4
Number of seats 5
Trunk volume (L) 453
Electric motor
Motor type Permanent magnet synchronization
Total motor power (kw) 100
Total motor torque [Nm] 225
Front motor maximum power (kW) 100
Front motor maximum torque (Nm) 225
Number of drive motors Single motor
Motor placement Prepended
Battery Type Lithium iron phosphate battery
NEDC pure electric cruising range (KM) 410
Number of gears 1
Transmission type Fixed gear ratio gearbox
Short name Electric vehicle single speed gearbox
Chassis Steer
Form of drive FF
Type of front suspension McPherson independent suspension
Type of rear suspension Torsion Beam Dependent Suspension
Boost type Electric assist
Car body structure Load bearing
Wheel braking
Type of front brake Ventilated Disc
Type of rear brake  Disc
Type of parking brake Electric brake
Front Tire Specifications 215/55 R17
Rear tire specifications 215/55 R17
Cab Safety Information
Primary driver airbag YES
Co-pilot airbag YES
Tire pressure monitoring function Tire pressure display
Seat belt not fastened reminder Front row
ISOFIX Child seat connector YES
ABS anti-lock YES
Brake force distribution (EBD/CBC, etc.) YES
Brake Assist (EBA/BAS/BA, etc.) YES
Traction Control (ASR/TCS/TRC, etc.) YES
Body Stability Control (ESC/ESP/DSC, etc.) YES
Assist/Control configuration
Front parking radar ~
Rear parking radar YES
Driving assistance video Reverse image
Cruise system Cruise control
Driving mode switching Sport/Economy/Standard Comfort
Automatic parking YES
Hill assist YES
External / Anti-Theft Configuration
Rim material Steel
Interior central lock YES
Key type Remote control key
Keyless start system YES
Battery preheating YES
Internal configuration
Steering wheel material Plastic
Steering wheel position adjustment Manual up and down
Multifunction steering wheel YES
Trip computer display screen  Color
LCD meter size (inch) 3.5
Seat configuration
Seat materials Imitation leather
Driver's seat adjustment Front and rear adjustment, backrest adjustment,height adjustment (2-way)
Co-pilot  seat adjustment Front and rear adjustment, backrest adjustment
Rear seats folded down Proportion down
Front/rear center armrest Front
Multimedia configuration
Central control color screen Touch LCD
Central control screen size (inch) 12.3
Satellite navigation system YES
Navigation traffic information display YES
Roadside assistance call YES
Bluetooth/Car Phone YES
Mobile phone interconnection/mapping Support CarLife
Voice recognition control system Multimedia system, navigation, telephone, air conditioning
Internet of Vehicles YES
OTA upgrade YES
Multimedia/charging interface USB
Number of USB/Type-c ports 2 in front/2 in rear
Number of speakers (pcs) 2
Lighting configuration
Low beam light source Halogen
High beam light source Halogen
Headlight height adjustable YES
Headlights turn off YES
Glass/Rearview mirror
Front power windows YES
Rear power windows YES
Window one-button lift function Driver's seat
Window anti-pinch function YES
Post audition feature Electric adjustment
Inside rearview mirror function Manual anti-dazzle
Air conditioner/refrigerator
Air conditioner temperature control method Automatic air conditioner
Rear air outlet YES
Temperature zone control YES
